SolaX X3 Hybrid G4 (Three Phase) Inverter Range

Product image 1
1 / 3

SolaX X3 Hybrid G4 (Three Phase) Inverter Range

SolaX X3 Hybrid G4 (Three Phase) Inverter Range

The SolaX X3 Hybrid G4 series is a state-of-the-art three-phase hybrid inverter range, designed for both residential and commercial solar-plus-storage projects. These inverters combine advanced solar PV conversion with high-voltage battery storage, delivering reliable backup power, intelligent energy management, and seamless integration with smart loads and EV charging.

Key Features

  • Available sizes: 5kW, 6kW, 8kW, 10kW, 12kW, 15kW
  • Hybrid functionality: solar PV inverter and battery storage controller in one
  • In-built EPS (Emergency Power Supply) changeover switch for backup
  • Supports up to 200% PV oversizing and up to 110% AC output
  • Three-phase unbalanced output: up to 5kW per phase
  • On-grid and off-grid operation, with parallel function up to 150kW
  • Max. 28A input per MPPT for high-power solar panels
  • 30A charge/discharge capability for rapid battery cycling
  • Works at full capacity down to -35°C
  • UPS-level switchover time <10ms
  • Type II SPD (Surge Protection Device) on both AC and DC sides
  • IP65 protection for indoor or outdoor installation
  • Includes WiFi dongle for remote monitoring and management
  • Smart load management (supports heat pumps, EV chargers, etc.)
  • VPP-ready (Virtual Power Plant) and ancillary service support
  • Quick configuration via USB drive

Model Range & Specifications

  • AC Output Power: 5.0kW, 6.0kW, 8.0kW, 10.0kW, 12.0kW, 15.0kW (model dependent)
  • Max. PV Input Power: Up to 200% of inverter rating (e.g. 20kW PV for 10kW inverter)
  • Max. PV Input Voltage: 1000V (model dependent)
  • MPPT Voltage Range: Typically 180–950V (model dependent)
  • Number of MPPTs: 2 (most models)
  • Max. Input Current per MPPT: Up to 28A
  • Battery Voltage Range: 180V – 650V (model dependent)
  • Max. Charge/Discharge Current: 30A
  • Max. Efficiency: Up to 98%
  • Charge/Discharge Efficiency: Up to 97.5%
  • Operating Temperature Range: -35°C to +60°C
  • Warranty: 10–12 years (model/distributor dependent)

Applications

  • Residential and commercial solar-plus-storage systems
  • Backup power for critical loads
  • Smart home and building energy management
  • Flexible grid services and VPP participation
